Toro TX 1300 - Replacing the Tracks

4.Loosentheboltsontherearcoverandremove
thecover.
g363402
Figure85
1.Rearcover
2.Bolt(2)
5.Loosenthejamnutandturnthetensioning
screwclockwiseuntilthetrackdeectionis19
mm(3/4inch).
g363401
Figure86
1.Tensioningscrew2.Jamnut
6.Tightenthejamnut.
7.Installthecoverandtightenthebolts.
8.Repeattheprocedurefortheothertrack.
9.Drivethemachine,thenparkthemachineona
levelsurface,engagetheparkingbrake,shutoff
theengine,andremovethekey.
10.Verifythatthetrackdeectionis19mm(3/4
inch).Adjustifnecessary.
ReplacingtheTracks
RemovingtheTracks
1.Removeanyattachments.
2.Parkthemachineonalevelsurface,ensuring
thatonly1sprockethalfisengagedwiththe
track.
g361326
Figure87
1.Sprockethalf
3.Lowertheloaderarms.
4.Shutofftheengineandremovethekey.
5.Raisethemachineoffthegroundsothatthe
bottomofthetrackisatleast10.2cm(4inches)
offtheground.Supportthemachineusingjack
stands.
Note:Usejackstandsratedforyourmachine.
WARNING
Mechanicalorhydraulicjacksmayfailto
supportthemachineandcauseserious
injury.
Usejackstandswhensupportingthe
machine.
6.Loosentheboltsontherearcoverandremove
thecover.
g363402
Figure88
1.Rearcover
2.Bolt(2)
57
