g014860
Figure12
1.Lever3.Detentslot
2.Proprod
2.Pulltheproprodintothedetentslot,securing
thebox(Figure13).
g029622
Figure13
1.Detentslot2.Proprod
LoweringtheCargoBox
WARNING
Theweightoftheboxmaybeheavy.Hands
orotherbodypartscouldbecrushed.
Keepyourhandsandotherbodypartsclear
whenloweringthebox.
1.Raisethecargoboxslightlybyliftinguponthe
latchlever(Figure12).
2.Pulltheproprodoutofthedetentslot(Figure
13).
3.Lowertheboxuntilitlatchessecurelyintoplace
(Figure13).
OpeningtheTailgate
1.Ensurethatthecargoboxisdownandlatched.
2.Liftupthengerpullsatthebackpanelofthe
tailgate(Figure14).
g024490
Figure14
1.Tailgateange(cargobox)3.Liftup(ngerpull)
2.Lockange(tailgate)
4.Rotaterearwardanddown
3.Alignthelockangesofthetailgatewiththe
openingsbetweenthetailgateangesofthe
cargobox(Figure14).
4.Rotatethetailgaterearwardanddown(Figure
14).
ClosingtheTailgate
Ifyouunloadedloosematerialsuchassand,
landscapingrock,orwoodchipsfromthecargoboxof
themachine,someofthematerialthatyouunloaded
mayhavelodgedinthehingeareaofthetailgate.
Performthefollowingbeforeclosingthetailgate.
1.Useyourhandstoremoveasmuchofthe
materialfromthehingeareaaspossible.
2.Rotatethetailgatetoapproximatelythe45°
position(Figure15).
19
