Toro Workman MDX-D - Greasing the Wheel Bearings; Removing the outboard bearing and bearing race

g033049
Figure31
1.Spindle
2.Hubandrotorassembly
7.Wipecleanthespindlewitharag.
8.Repeatsteps1through7tothehubandrotorat
theothersideofthemachine.
GreasingtheWheelBearings
1.Removetheoutboardbearingandbearingrace
fromthehub(Figure32).
g033050
Figure32
1.Seal4.Bearingcavity(hub)
2.Inboardbearing
5.Outboard-bearingrace
3.Inboard-bearingrace
6.Outboardbearing
2.Removetheseal,inboardbearingfromthehub
(Figure32).
3.Wipecleanthesealandcheckforwearand
damage.
Note:Donotusecleaningsolventtocleanthe
seal.Replacethesealifitiswornordamaged.
4.Cleanthebearingsandraces,andcheckthese
partsforwearanddamage.
Note:Replaceallwornordamagedparts.
Ensurethatthebearingsandracesareclean
anddry.
5.Cleanthecavityofthehubofallgrease,dirt,
anddebris(Figure32).
6.Packthebearingswiththespeciedgrease.
7.Fillthecavityofhub50to80%fullofthe
speciedgrease(Figure32).
8.Assembletheinboardbearingontotheraceat
theinboardsideofthehubandinstalltheseal
(Figure32).
9.Repeatsteps1through8tothebearingsforthe
otherhub.
32
