Toro Workman MDX-D User Manual

DisconnectingtheBattery
WARNING
Incorrectbatterycableroutingcoulddamage
themachineandcables,causingsparks.
Sparkscancausethebatterygassesto
explode,resultinginpersonalinjury.
•Alwaysdisconnectthenegative(black)
batterycablebeforedisconnectingthe
positive(red)cable.
•Alwaysconnectthepositive(red)battery
cablebeforeconnectingthenegative
(black)cable.
•Alwayskeepthebatterystrapinplaceto
protectandsecurethebattery.
WARNING
Batteryterminalsormetaltoolscouldshort
againstmetalmachinecomponents,causing
sparks.Sparkscancausethebatterygasses
toexplode,resultinginpersonalinjury.
•Whenremovingorinstallingthebattery,
donotallowthebatteryterminalstotouch
anymetalpartsofthemachine.
•Donotallowmetaltoolstoshortbetween
thebatteryterminalsandmetalpartsofthe
machine.
1.Squeezethesidesofthebatterycoverand
removethecoverfromthetopofthebattery
(Figure40).
g024429
Figure40
1.Positivebatteryterminal5.Batterycover
2.Positivebatterycable6.Batteryclamp
3.Negativebatterycable7.Locknut
4.Negativebatteryterminal
8.Carriagebolt
2.Disconnectthenegativebatterycablefromthe
terminalofthebattery(Figure40).
3.Disconnectthepositivebatterycablefromthe
terminalofthebattery(Figure40).
RemovingtheBattery
1.Disconnectthebatterycables;referto
DisconnectingtheBattery(page38).
2.Removethelocknut,carriagebolt,andbattery
clampthatsecuresthebatterytothebatterytray
(Figure40).
3.Removethebatteryfromthebatterytray(Figure
40).
38
