model 2000 DeviceNet Module Manual (DN611/DN611A)
Chapter 6 RAS Information (Except for RAS Area in Communication Memory)
6
RAS_CNT[23] 02DEH H Number of output data write requests (bit strobe)
RAS_CNT[24] 02DFH L Number of output data write responses (bit strobe)
RAS_CNT[25] 02DFH H Number of output data write requests (polling)
RAS_CNT[26] 02E0H L Number of output data write responses (polling)
RAS_CNT[27] 02E0H H Number of explicit message requests
RAS_CNT[28] 02E1H L Number of explicit message responses
RAS_CNT[29] 02E1H H Number of invalid request codes received
RAS_CNT[30] 02E2H L Content of invalid request code received
RAS_CNT[31] 02E2H H Number of normal responses
RAS_CNT[32] 02E3H L Number of abnormal responses
RAS_CNT[33] 02E3H H Transmission MBX memory pool error (for data)
RAS_CNT[34] 02E4H L Transmission MBX memory pool error (MBX)
RAS_CNT[35] 02E4H H MBX transmission error
RAS_CNT[36] 02E5H L MBX reception error
RAS_CNT[37] 02E5H H Received data size 0 byte
RAS_CNT[38] 02E6H L Receive MBX release error (for data)
RAS_CNT[39] 02E6H H MBX reception normal
RAS_CNT[40] 02E7H L Down code
RAS_CNT[41] 02E7H H Down detail code
RAS_CNT[42] 02E8H L Number of confirm register 2-second waits
RAS_CNT[43] 02E8H H Number of indication register 2-second waits
RAS_CNT[44] 02E9H L EP-ROM scan list CRC error
RAS_CNT[45] 02E9H H Number of DBASE normal scan lists
RAS_CNT[46] 02EAH L Number of scan list settings (EP-ROM)
RAS_CNT[47] 02EAH H Bit strobe 20-ms response wait
RAS_CNT[48] 02EBH L Number of overruns
RAS_CNT[49] 02EBH H Number of errors active
RAS_CNT[50] 02ECH L Number of errors passive
RAS_CNT[51] 02ECH H Number of busoffs
RAS_CNT[52] 02EDH L Number of transmission interrupts
RAS_CNT[53] 02EDH H Number of received data ID errors
RAS_CNT[54] 02EEH L NMI error
RAS_CNT[55] 02EEH H DeviceNet request data timeout
RAS_CNT[56] 02EFH L I/O connection inactivity timeout
RAS_CNT[57] 02EFH H Explicit connection inactivity timeout
RAS_CNT[58] 02F0H L Vendor ID invalid
RAS_CNT[59] 02F0H H Project type invalid
RAS_CNT[60] 02F1H L Project code invalid
RAS_CNT[61] 02F1H H Transmitted maximum data length different (polling)
RAS_CNT[62] 02F2H L Transmitted maximum data length different (COS)
Table 6-4 RAS Counter List (2/3)
Symbol name Address Description
