6.3 RAS Information Read Data
6
RAS_CNT[63] 02F2H H Received maximum data length different (No fragment)
RAS_CNT[64] 02F3H L Connection table fragment buffer acquisition failure
RAS_CNT[65] 02F3H H Fragment data type error
RAS_CNT[66] 02F4H L Fragment data intermediate counter error
RAS_CNT[67] 02F4H H Fragment data final counter error
RAS_CNT[68] 02F5H L Received maximum size over
RAS_CNT[69] 02F5H H Received data length error (fragment data)
RAS_CNT[70] 02F6H L Polling 20-ms response wait
RAS_CNT[71] 02F6H H NMI read port read value
RAS_CNT[72] 02F7H L Number of CAN transmissions
RAS_CNT[73] 02F7H H CAN transmission disabled (content of status register)
RAS_CNT[74] 02F8H L
RAS_CNT[75] 02F8H H
RAS_CNT[76] 02F9H L
RAS_CNT[77] 02F9H H
RAS_CNT[78] 02FAH L
RAS_CNT[79] 02FAH H
RAS_CNT[80] 02FBH L
RAS_CNT[81] 02FBH H
RAS_CNT[82] 02FCH L
RAS_CNT[83] 02FCH H
RAS_CNT[84] 02FDH L
RAS_CNT[85] 02FDH H
RAS_CNT[86] 02FEH L
RAS_CNT[87] 02FEH H
RAS_CNT[88] 02FFH L
RAS_CNT[89] 02FFH H
RAS_CNT[90] 0300H L
RAS_CNT[91] 0300H H
RAS_CNT[92] 0301H L
RAS_CNT[93] 0301H H
RAS_CNT[94] 0302H L
RAS_CNT[95] 0302H H
RAS_CNT[96] 0303H L
RAS_CNT[97] 0303H H
RAS_CNT[98] 0304H L
RAS_CNT[99] 0304H H
Table 6-4 RAS Counter List (3/3)
Symbol name Address Description
To Next Page
