Toshiba B-EX4 SERIES - 1. Unpacking Procedures; 1.1 Procedures

1. OUTLINE EO10-33024
1.4 BASIC SPECIFICATIONS
1- 5
16) Mechanism
(1)Mechanism








(2) Label Sensor













Distance between ribbon
end sensor and print head
15.3 mm
Distance between label
sensor and print head
75.5mm
Distance between ribbon end
sensor and print head
47.4 mm
Distance between peel off
plate and print head
13.75mm
Tran missive sensor
Reflect sensor
10 mm
60 mm
(Center of paper)
