Toshiba B-EX4 T1 Series User Manual

1. OUTLINE SPTM-0152
1.4 BASIC SPECIFICATIONS
1-8
17) Power supply
CN model: AC220 - 240 V ±10%, 50Hz
QM model: AC100 - 240 V ±10%, 50/60Hz
Global(QM) China(CN)
Input voltage/frequency
AC100V-240V
±10%
50-60Hz
AC100V-240V ±10%
50Hz
AC cord Not include Not include
100V: 22A
240V: 71A
240V: 71A Rush current
In order to exceed 10A, explane to users set up
exclusive plug socket.
Sleep
(Factory inital)
5.7W 0.09A 5.7W 0.09A
Stand-by
(Maximum)
Less than 8W (Print ready)
Less than 15W (Option full-operating)
Power
consumption
Operation *1 157.34W
2.0A-0.7A
157.34W
2.0A-0.7A
Power
supply
specification
Energy star appliance Yes
*1 An operation is a power consumption at the time of a 20% slant line.
(It is based on a specification test format.)
18) Current consumption
[B-EX4T2]
QM-R & CN-R model (100V) QM-R & CN-R model (240V)
Printing 166.31W,1.6888A 157.34W, 0.7147 A
Sleep mode 4.5W, 0.0893A 5.7W, 0.0861A
NOTES:
Be sure to provide an exclusive AC outlet for this machine. (This is 20% slant line print)
Energy Star Program appliance
19) Rush current
QM model: 100V: 22.1A, 240V: 70.6A

Toshiba B-EX4 T1 Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi, 300 dpi, 600 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fanfold
Connectivity	USB 2.0, Ethernet
Optional Interfaces	Wireless LAN
Media Thickness	0.06 mm to 0.17 mm
Ribbon Width	40 – 110 mm
Barcodes	Code 39, Code 128, UPC/EAN/JAN, Postnet
2D Codes	Data Matrix, PDF417, QR Code, MaxiCode
