Toshiba B-EX4 T1 Series User Manual

1. OUTLINE SPTM-0152
1.4 BASIC SPECIFICATIONS
1-7
(3) Cutter mechanism
When the cutter module is installed, the backing paper of the label stock or tag paper is cut
individually.
Disk cutter: Stop and cut
Item Specification
Cutter type DISK CUTTER
Paper width 30.0mm -
Tag
25.4- 500mm
(T.B.D)
Cut
length
Label
38.0 - 1500mm
(T.B.D)
Possible
cut size
Thickness 80 - 170μm(T.B.D)
Cutter life 1,000,000 cut (160μm tag) (T.B.D)
* Cutter life is confirmed by using same width paper.
Disk Cutter:21.9

Toshiba B-EX4 T1 Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi, 300 dpi, 600 dpi
Max Print Width	4.09 inches (104 mm)
Media Type	Roll, Fanfold
Connectivity	USB 2.0, Ethernet
Optional Interfaces	Wireless LAN
Media Thickness	0.06 mm to 0.17 mm
Ribbon Width	40 – 110 mm
Barcodes	Code 39, Code 128, UPC/EAN/JAN, Postnet
2D Codes	Data Matrix, PDF417, QR Code, MaxiCode
