Toshiba B-SA4T Series Product Description

EO10-33016A
(Revision Date: Feb. 14, 2008)
TABLE OF CONTENTS
Page
1. OUTLINE -------------------------------------------------------------------------------------------------1- 1
1.1 Printer Specifications--------------------------------------------------------------------------------------1- 1
1.2 Description of Model Number ---------------------------------------------------------------------------1- 1
1.3 Appearance and Dimensions (Approximate) -------------------------------------------------------1- 2
1.3.1 Front View/Rear View ---------------------------------------------------------------------------1- 2
1.3.2 Operation Panel-----------------------------------------------------------------------------------1- 2
1.3.3 Dimensions (Approximate)---------------------------------------------------------------------1- 2
1.3.4 Weight-----------------------------------------------------------------------------------------------1- 2
1.4 Basic Specifications ---------------------------------------------------------------------------------------1- 3
1.5 Electronics Specifications--------------------------------------------------------------------------------1- 7
2. SUPPLY SPECIFICATIONS-------------------------------------------------------------------------2- 1
2.1 Media --------------------------------------------------------------------------------------------------------2- 1
2.2 Ribbon --------------------------------------------------------------------------------------------------------2- 5
2.3 Care and Handling of the Media and Ribbon -------------------------------------------------------2- 6
2.4 Specification of RFID Tag--------------------------------------------------------------------------------2- 7
3. OPTIONAL KIT -----------------------------------------------------------------------------------------3- 1
3.1 Cutter Module: B-SA204-QM/B-SA204-QM-R------------------------------------------------------3- 1
3.2 Strip Module: B-SA904-H-QM-R -----------------------------------------------------------------------3- 2
3.3 Serial Interface Board: B-SA704-RS-QM-R ---------------------------------------------------------3- 3
3.4 Wireless LAN Board: B-SA704-WLAN-QM----------------------------------------------------------3- 4
3.5 300-Dpi Print Head: B-SA704-TPH3-QM-R ---------------------------------------------------------3- 8
3.6 Expansion I/O Board: B-SA704-IO-QM-R -----------------------------------------------------------3- 8
3.7 Real Time Clock: B-SA704-RTC-QM-R --------------------------------------------------------------3- 9
3.8 RFID Module: B-SA704-RFID-U2-EU-R ------------------------------------------------------------ 3-10
CAUTION!
1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA
TEC.
2. The contents of this manual may be changed without notification.
3. Please refer to your local Authorised Service representative with regard to any queries you
may have in this manual.
Copyright © 2005
by TOSHIBA TEC CORPORATION
A
ll Rights Reserved
570 Ohito, Izunokuni-shi, Shizuoka-ken, JAPAN
NOTE:
Though the pictures used in this document are mostly those of the B-SA4TM (Metal cover model), the
replacement procedures are in common with the B-SA4TP (Plastic cover model).
[B-SA4TM] [B-SA4TP]

Toshiba B-SA4T Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Speed	Up to 152.4 mm/sec (6 ips)
Max Print Width	104 mm (4.09")
Resolution	300 dpi
Connectivity	USB 2.0
Optional Interfaces	Wireless LAN
Barcodes	UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, Industrial 2 of 5, Postnet, RM4SCC, KIX-Code
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code, Micro PDF417, Aztec Code
Media Thickness	0.06 – 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Length	Up to 300 m
Weight	15 kg
