3. OPTIONAL KIT EO10-33016A
3.4 Wireless LAN Board: B-SA704-WLAN-QM
3- 4
3.4 Wireless LAN Board: B-SA704-WLAN-QM
Hardware Specification
Item Specification
Wired LAN part Connected to a wired LAN port of the printer.
Transfer mode Conforming to IEEE802.11a
Orthogonal Frequency-Division
Multiplexing (OFDM)
Channel Depending on countries
Transmission speed 54, 48, 36, 24, 18, 12, 9, 6 (Mbps)
(Fix/automatic)
Access method CSMA/CA+ACK (RTS/CTS)
Wireless category Small power data communication
system (5.150 to 5.250GHz)
IEEE802.11a
Radio wave power 10mW/MHz or less
Transfer mode Conforming to IEEE802.11b
DSSS
Channel Depending on countries
Transmission speed 11, 5.5, 2, 1 (Mbps)
(Fix/automatic)
Access method CSMA/CA+ACK (RTS/CTS)
Wireless category Small power data communication
system (2.4 to 2.497GHz)
IEEE802.11b
Radio wave power 10mW/MHz or less
Transfer mode Conforming to IEEE802.11g
OFDM, DSSS
Channel Depending on countries
Transmission speed 54, 48, 36, 24, 18, 12, 9, 6, 11, 5.5, 2,
1 (Mbps) (Fix/automatic)
Access method CSMA/CA+ACK (RTS/CTS)
Wireless category Small power data communication
system (2.4 to 2.4835GHz)
IEEE802.11g
Radio wave power 10mW/MHz or less
Wireless LAN part
Antenna Chip type, diversity antenna
Software Specification
Item Specification
Unit type Access point [Station]
Operating mode Standard, [Compatible], Advanced
Default country code US
Default IP address 192.168.10.21
Default subnet mask 255.255.255.0
Default password Described separately.
Encryption WEP (64.128.152 bit) or AES, AES-OCB (128 bit)
TKIP (only when using WPA, WPA-PSK)
TWSL (Unique encryption) only when a POS is connected.
Parameter setting Browser or telnet (For telnet, internal use only)
Browser Microsoft IE5.01 or greater
Protocol IP (RFC791), ICMP (RFC792), UDP (RFC768)
TCP (RFC793, 896), ARP (RFC826), HTTPD (RFC1866), TELNET
FTPD (RFC959), DHCP (RFC2131), SNMP
