Toshiba B-SA4T Series - 3 Optional Kit; Cutter Module: B-SA204-QM;B-SA204-QM-R

3. OPTIONAL KIT EO10-33016A
(Revision Date: Feb. 14, 2008)
3. OPTIONAL KIT
3- 1
3. OPTIONAL KIT
Option Name Type Usage
300-dpi Print
Head
B-SA704-TPH3-QM-R This print head enables a conversion of a 203-dpi print
head of the B-SA4TM-GS12 model into a 300-dpi print
head. This option is intended for use when you desire to
print Kanji (Chinese characters) or to obtain clearer print.
Cutter module B-SA204-QM-R
B-SA204P-QM-R
B-SA204-QM
A cutter which cuts the media one by one. This module is
slim and compact enough to be fitted in the Front Cover.
NOTE: The B-SA204-QM and the B-SA204-QM-R are
exclusively for the B-SA4TM series.
The SA-204P-QM-R is exclusively for the B-SA4P
series.
Strip module B-SA904-H-QM-R
B-SA904P-H-QM-R
This module peels off a printed label from the backing
paper at the media outlet. It is slim and compact enough to
be fitted in the Front Cover.
NOTE: The B-SA904-H-QM-R is exclusively for the B-
SA4TM series. The B-SA904P-H-QM is
exclusively for the B-SA4TMP series.
Serial Interface
Board
B-SA704-RS-QM-R Installing this PC board provides an RS232C interface port.
Wireless LAN
Board
B-SA704-WLAN-QM
B-SA704-WLAN-QM-R
Installing this PC board allows a communication by wireless
LAN.
RFID module B-SA704-RFID-U2-EU-R Installing this module enables read and write of RFID tags.
Frequency range: 869.7-870.0MHz (Center frequency:
869.85MHz).
Available RFID tag type: EPC C1 Gen2.
Expansion I/O
Board
B-SA704-IO-R-QM Installing this board in the printer allows a connection with
an external device with the exclusive interface.
Real Time Clock B-SA704-RTC-QM-R This module holds the current time: year, month, day, hour,
minute, second
NOTE: To purchase the optional kits, please contact the TOSHIBA TEC Head Quarters.
