3. OPTIONAL KIT EO10-33016A
3.2 Strip Module: B-SA904-H-QM-R
3- 2
3.1 Cutter Module: B-SA204-QM/B-SA204-QM-R/B-SA204P-QM-R
Item Specification
Cutting method Guillotine cutter
Media to be cut Thermal paper, normal paper, label stock
Media thickness 80 to 290µm
Rated voltage DC24V ±5%
Cutter life 80 to 160mm-thick paper: 1000000 cuts
160 to 290mm-thick paper: 500000 cuts
Operating environment
Temperature
Humidity
0 to 40°C
25 to 85% RH (No condensation)
Storage environment
Temperature
Humidity
-10 to 50°C
5 to 90% RH (No condensation)
Media feed speed 2”/sec., 4”/sec., 6”/sec.
Cutting time 0.5 sec. or less/cut
Cut cycle 2 sec. or more/cycle
Dimension 184mm (W) x 212mm (H) x 87mm (D)
Weight Approximate1500 g
Safety device Power supply is stopped when the interlock switch detects an open of
the cutter front cover.
Removal of jammed
media
In case of a cutter error due to a media jam, rotate the cutter motor shaft
by hand to remove the jammed media.
3.2 Strip Module: B-SA904-H-QM-R/B-SA904P-H-QM-R
Item Specification
Peel off method Backing paper feed rollers draw the backing paper.
Media to be stripped Thermal label, normal label
Backing paper width 25.4mm to 114 mm
Label width 21.4 to 110 mm
Label length 13 to 997 mm
Label pitch 15 to 999 mm
Gap length 2 to 5 mm
Effective print length 11 to 995 mm
Media thickness 130 to 170µm
Operating environment
Temperature
Humidity
0 to 40°C
25 to 85% RH (No condensation)
Storage environment
Temperature
Humidity
-40 to 60°C
10 to 90% RH (No condensation)
Strip speed 2 ips, 4 ips, 6 ips
Dimension 146mm (W) x 201 mm (H) x 50mm (D) (Front cover is not included.)
Weight Approximate 1000 g
NOTE: Labels of which length exceeds 76.2 mm may stick to the media outlet after it is stripped from the
backing paper.
