3. OPTIONAL KIT EO10-33016A
(Revision Date: Jan. 19, 2006)
3.5 300-Dpi Print Head: B-SA704-TPH3-QM-R
3- 8
3.5 300-Dpi Print Head: B-SA704-TPH3-QM-R
Item Specification
Print head type KPG-106-12TAO4-TE
Effective print width 105.7±0.2mm
Number of dots 1248 dots
Resolution 11.8 dots/mm
Thermal element pitch 0.0847 mm
Average resistance 1000 ohm±3%
STROBE 2 strobe
Data input method 4 data input
Glazing
Width
Height
700µm
25µm
Operating environment
Temperature
Humidity
0 to 40°C
20 to 90% RH (No condensation)
Storage environment
Temperature
Humidity
-5 to 50°C
5 to 90% RH (No condensation)
Applied voltage 24 V
NOTES:
1. Do not touch the print head by bare hands.
2. Use TOSHIBA TEC approved media only.
3. Do not perform printing when the printer built up dew condensation.
4. Use a print head cleaner or a cotton swab or soft cloth slightly moistened with absolute ethyl alcohol to
clean the print head element.
5. Care must be taken not to damage the print head by hitting a hard or sharp object against it.
3.6 Real Time Clock: B-SA704-RTC-QM-R
Item Specification
Clock function Time counter (second/minute/hour) and calendar counter (day/day of
the week/month/year)
Automatic adjustment of leap years
Battery-powered time keeping
Accuracy RRT daily variance ±4 sec. (25°C)
Functions Time and calendar data printing
Low battery voltage detection
Clock adjustment function
Battery CR2032 (Standardized products can be used.)
Battery life Approximately 2 years or more when the battery is fully charged.
The battery power is burned as long as the battery is installed, as the
real time clock automatically functions.
Operating Environment
Temperature
Humidity
0°C to 40°C
20% to 90% (No condensation)
To Next Page
