Toshiba B-SA4T Series Product Description

2. SUPPLY SPECIFICATIONS EO10-33016A
2.2 Ribbon
2- 5
2.2 Ribbon
(1) Specification of Ribbon
No.
Item Specification
1 Shape Spool type
2 Width 60 to 110 mm (Recommended width is 60, 90, and 110 mm)
3 Max. length 450 m (within ø 75 mm)
4 Max. outer diameter ø 75 mm
5 Back treatment Coated
Material Cardboard 6 Core
Shape See the following figures.
7 Leader tape Polyester film (Opaque), 260 ± 5 mm long
8 End tape None
9 Winding method The ink side faces outside of ribbon winding
NOTES: 1. To ensure print quality and print head life use only TOSHIBA TEC specified ribbons.
2. Too much difference in width between media and ribbon may cause ribbon wrinkles. To avoid
ribbon wrinkles use a ribbon for proper media width shown in the above table. Do not use a
ribbon that is narrower than media.
.
Ribbon width 60 mm 90 mm 110 mm
Proper media width 25 to 55 mm 55 to 85 mm
85 to 105mm
(2) Ribbon Core Shape
NOTE: When purchasing ribbon locally, they must meet the above size. There may be TOSHIBA TEC-
approved ribbons which do not fall within the above size, however, they have no functional problem.
25.8 ±0.2 mm
Max. 118 –0, -0.5mm

Toshiba B-SA4T Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Speed	Up to 152.4 mm/sec (6 ips)
Max Print Width	104 mm (4.09")
Resolution	300 dpi
Connectivity	USB 2.0
Optional Interfaces	Wireless LAN
Barcodes	UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, Industrial 2 of 5, Postnet, RM4SCC, KIX-Code
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code, Micro PDF417, Aztec Code
Media Thickness	0.06 – 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Length	Up to 300 m
Weight	15 kg
