1. OUTLINE EO10-33016A
1.1 Printer Specifications
1- 1
1. OUTLINE
1.1 Printer Specifications
1) Various bar codes, characters and graphic data can be printed using both thermal transfer and thermal
direct methods. This printer can also print writable characters and logos at designated coordinates by
using a graphic command.
2) Centronics, LAN, and USB are provided as standard interfaces for communicating with a PC.
Additionally, serial interface and wireless LAN interface are optionally available.
3) A 32-bit CPU and a Field Programmable Gate Array (FPGA) equipped with several peripheral LSIs
realizes high system performance.
4) An area required to place a printer is about A4 size, in spite of both media and ribbon being loaded
inside it. Also, the Top Cover is opened upward, which saves the installation space.
5) Clear print is realized by an 8 dots/mm (203 dpi) (GS12 model) or 11.8 dots/mm (300 dpi) (TS12 model)
print head, at a printing speed of 50.8 mm/sec. (2 inches/sec.), 101.6 mm/sec. (4 inches/sec.), or 152.4
mm/sec. (6 inches/sec.)
6) As the enclosure is made of metal, the printer can be used in an industrial environment such as a factory.
7) Design of the printer is simple. Especially, attachment and removal of the print head and platen are very
simple, which makes maintenance easy.
8) Optional cutter module or optional strip module will expand the application of the printer.
NOTE: Every size is written in millimeter (mm) in this manual. To obtain the size in inch, divide by 25.4.
1.2 Description of Model Number
B – S A 4 T M – G S 1 2 – Q M - R
RoHS compliant
Destination Code
QM: Standard for Worldwide
CN: China
Machine Type
Machine Version
Issue mode
S: Batch
Resolution
G: 8 dots/mm (203 dpi)
T: 11.8 dots/mm (300 dpi)
Material of enclosure
M: Metal
P: Plastic
Printing method:
T: Thermal direct or Thermal transfer
Printing width
4: 4 inches
To Next Page
