Toshiba B-SA4T Series Product Description

1. OUTLINE EO10-33016A
1.4 Basic Specifications
1- 5
12) White or black background all types of characters are available.
13) Character rotation: 0
°, 90°, 180°, 270°
14) Character strings rotation: 0
°, 90°, 180°, 270°
15) Type of line
(1) Horizontal line (2) Vertical line (3) Slant line (4) Square (5) Rounded Rectangle (6) Circle
16) Line Width: 0.1 to 9.9 mm can be specified (in units of 0.1 mm)
17) Mechanism
(1) Batch mechanism
This is the standard mechanism which lets the printer print continuously until the number of media
specified in the label issue command has been printed.
(2) Strip mechanism (Option)
When an optional strip module is attached, a label is stripped from the backing paper by the strip
shaft, and the backing paper is drawn into the strip module. The next label will not be printed until
the preceding label is removed, as a presence of the label at the strip shaft is monitored by the strip
sensor.
Ribbon
Print Head
Platen
Black Mark Sensor
Tag Stock
Strip Sensor
Strip Shaft
Feed Gap Sensor
Label Stock

Toshiba B-SA4T Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Print Speed	Up to 152.4 mm/sec (6 ips)
Max Print Width	104 mm (4.09")
Resolution	300 dpi
Connectivity	USB 2.0
Optional Interfaces	Wireless LAN
Barcodes	UPC/EAN/JAN, Code 39, Code 93, Code 128, EAN 128, NW7, Industrial 2 of 5, Postnet, RM4SCC, KIX-Code
2D Codes	Data Matrix, PDF417, QR Code, Maxi Code, Micro PDF417, Aztec Code
Media Thickness	0.06 – 0.19 mm
Media Roll Diameter	Max. 127 mm
Ribbon Length	Up to 300 m
Weight	15 kg
