48 P9 ASD Installation and Operation Manual
Program Mode Menu Navigation
The following table lists the menu items of the Program mode and maps the flow of the menu selections.
The Parameter Numbers for the listed functions are provided where applicable.
The functions listed may be viewed, or selected and changed as mapped below or via the Direct Access
method: Program Direct Access Applicable Parameter Number.
Program Mode Menu Navigation
Primary Menu Sub Menu Parameter Name
Parameter
Number
V
IRTUAL
L
INEAR
P
UMP
(See Virtual Linear
Pump Setup on pg. 73
for more on this
function.)
Setup Wizard
Motor/ASD Setup
N/A
Transducer Setup
Setup
Settings
Mode Switch F390
Application Type F391
Application Operating Mode F380
Transducer Units N/A
Transducer Output Range F392
Transducer Maximum Reading F393
Transducer Minimum Reading F403
Minimum (Threshold) F394
Maximum (Threshold) F395
Command Source F396
Command Value F397
Low Frequency Limit F398
Start and Stop Points
Start and Stop Mode F385
Start and Stop Delay Timer F387
Low Start and Stop Point F388
High Start and Stop Point F389
Input Terminal 5 (S1) Function F115
Sleep Timer
Sleep Timer F382
Sleep Timer Delay F383
Run External Devices
External Delay Timer F480
External Device Low Band F481
External Device High Band F482
