IF08CZ10 April, 2019 - 37 -
Analog Output
General-purpose Analog Output
Three channels (AOUT1, 2, and 3) are provided as general-purpose, 10VDC analog output from the
XIO brd.. These outputs are directly output from the control brd.. The device reading these signals must be
isolated. To insure this, it is recommended that signal isolators be used. The output can be selected from a
list shown in the parameter setting manual by using the parameters AOUT1-3_CODE. They may also be
set to any function in the drive by the use of the parameters AOUT1-3_OP_AS, AOUT1-3_OP_GS, and
AOUT1-3_OP_OS. When using the optional settings, care must be taken to set the output up so that the
output signal does not exceed 10VDC. Exceeding this value will cause overflow problems.
Additional Analog Outputs
Six channels (D/A 1 to D/A 5 and Amp A) are provided as additional analog outputs. These outputs
are wired out to terminal block TB-AO. Channel A provides direct current feedback from the U-phase Hall
CT. The other five channels are programmable 10VDC outputs. The data to be output, the gain, and the
offset, can be set from the display/keypad or a personal computer by use of parameters DA1-5_AS (Analog
Signal), DA1-5_GS (Signal Gain), and DA1-5_OS (Offset).
