TE2 Series Digital Solid State Soft Starter User Manual 69 | Page
Display Message Description
Fault Display
Code
Readout
Fault Number
Code used in
History,
F085, F088
and F091
LED
Indicator
Voltage Imbalance Fault During Accel
EI
A
40
N/A
Voltage Imbalance Fault During Constant Speed
EIc
41
Voltage Imbalance Fault During Decel (or Stop)
EId
42
Over Voltage Fault During Accel
oE
A
43
Over Voltage Fault During Constant Speed
oEc
44
Over Voltage Fault During Decel (or Stop)
oEd
45
Under Voltage During Accel
UE
A
46
Under Voltage During Constant Speed
UEc
47
Under Voltage During Decel (or Stop)
UEd
48
Power Factor Trip During Accel
PF
A
49
Power Factor Trip During Constant Speed
PFc
50
Power Factor Trip During Decel (or Stop)
PFd
51
PoweR (kW) Trip During Accel
Pr
A
52
PoweR (kW) Trip During Constant Speed
Prc
53
PoweR (kW) Trip During Decel (or Stop)
Prd
54
Control Power Loss Fault During Accel
ncP
A
55
Control Power Loss Fault During Constant Speed
ncPc
56
Control Power Loss Fault During Decel (or Stop)
ncPd
57
Table 7.1 Continued: Message Fault code List
