Toshiba Tecra A8 Maintenance Manual

TECRA A8 /Satellite Pro A120 Maintenance Manual (960-573) [CONFIDENTIAL] iii
Preface
This maintenance manual describes how to perform hardware service maintenance for the
Toshiba Personal Computer TECRA A8 series / Satellite Pro A120 series.
The procedures described in this manual are intended to help service technicians isolate
faulty Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your
attention. Each of these messages will be italicized and identified as shown below.
DANGER: “Danger” indicates the existence of a hazard that could result in death or
serious bodily injury, if the safety instruction is not observed.
WARNING: “Warning” indicates the existence of a hazard that could result in bodily
injury, if the safety instruction is not observed.
CAUTION: “Caution” indicates the existence of a hazard that could result in property
damage, if the safety instruction is not observed.
NOTE: “Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service
technicians and authorized dealers or service providers to ensure the following safety
precautions are adhered to strictly.
 Be sure to fasten screws securely with the right screwdriver. If a screw is not fully
fastened, it could come loose, creating a danger of a short circuit, which could cause
overheating, smoke or fire.
 If you replace the battery pack or RTC battery, be sure to use only the same model
battery or an equivalent battery recommended by Toshiba. Installation of the wrong
battery can cause the battery to explode.

Toshiba Tecra A8 Specifications

General

Processor cache	2 MB
Processor family	Intel® Core™2 Duo
Processor frequency	1.66 GHz
Processor manufacturer	Intel
Processor front side bus	667 MHz
HDD speed	5400 RPM
Optical drive type	DVD Super Multi DL
Card reader integrated	Yes
Total storage capacity	80 GB
Display diagonal	15.4 \
Display resolution	1280 x 800 pixels
Internal memory	1 GB
Internal memory type	DDR2-SDRAM
Maximum internal memory	4 GB
Maximum graphics card memory	0.128 GB
CD-R read speed	24 x
DVD+R write speed	8 x
DVD-RW write speed	4 x
DVD+R Double Layer write speed	2.4 x
DVD-R Double Layer write speed	2 x
Front camera	No
Modem speed	56 Kbit/s
Operating system installed	Windows Vista Business
TV-out type	S-Video
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Parallel ports quantity	0
CardBus PCMCIA slot type	Type II
Cable lock slot type	Kensington
Password protection type	BIOS
Pointing device	Touchpad

Weight and Dimensions

Depth	268 mm
Width	368 mm
Height	29.8 mm
Weight	3000 g
