E6581818
- 18 -
5.2.1.1. fa06 (Communication command1)
bit Function 0 1 Note
0
Preset speed
operation frequencies
1
1
Preset speed
operation frequencies
2
2
Preset speed
operation frequencies
3
3
Preset speed
operation frequencies
4
Preset speed operation is disabled
or preset speed operation
frequencies (1-15) are set by
specifying bits for preset speed
operation frequencies 1-4.
(0000: Preset speed operation OFF,
001-1111: Setting of preset speed
operation frequencies (1-15)
4
Motor selection (1 or 2)
(THR 2 selection)
Motor 1
(THR 1)
Motor 2
(THR 2)
THR 1: pt = setting value, thr
THR 2: pt = 0, f170,
f171, f172, f173
5 PI D control Normal operation PI D off -
6
Acceleration/decele-
ration pattern selection
(1 or 2)
(AD2 selection)
Acceleration/decel
eration pattern 1
(AD1)
Acceleration/dec
eleration pattern
2
(AD2)
AD1: acc, dec
AD2: f500, f501
7 DC braking OFF
Forced DC
braking
-
8 Jog run OFF Jog run -
9
Forward/reverse run
selection
Forward run Reverse run -
10 Run/stop Stop Run -
11 Coast stop command Standby Cost stop -
12 Emergency stop OFF Emergency stop Always enable, "E" trip
13 Fault reset OFF Reset No data is returned from the drive
14
Frequency priority
selection
OFF Enabled
Enabled regardless of the setting
of fmod
15
Command priority
selection
OFF Enabled
Enabled regardless of the setting
of cmod
* VF-S15:When 14(sr0) is set to fmod, preset speed operation frequency 0 is selected.
