E6581697
F-67
6
6.21.2 Setting motor constants for PM motors
f400 : Auto-tuning
f459 : Load inertia moment ratio
f402 : Automatic torque boost value f912 : q-axis inductance
f405 : Motor rated capacity f913 : d-axis inductance
f415 : Motor rated current f915 : PM control mode selection
f417 : Motor rated speed
To use vector control for PM motor is required. Setting V/F control mode selection (pt) should be set as 6.
Caution:
If the settings for V/F control mode selections
pt is 6: vector control for PM motor
Look at the motor's name plate and set the following parameters.
vl: Base frequency 1 (rated frequency) that is calculated from Back EMF
vlv: Base frequency voltage 1 (rated voltage) that is calculated from Back EMF
f405: Motor rated capacity
f415: Motor rated current
f417: Motor rated speed
f912: Q axis inductance per phase
f913: D axis inductance per phase
[Selection 1: Setting PM motor control and auto-tuning ]
After setting pt =6 , auto-tuning occurs.
Set the auto-tuning parameter f400 to 2 (Auto-tuning enabled)
[Parameter setting]
Title Function Adjustment range Default setting
f400 Auto-tuning
0: Auto-tuning disabled
1: Initialization of
f402,f912,f913
(after execution : 0)
2: Auto-tuning executed
(after execution: 0)
3: -
4: -
5: -
0
Note1) When parameter pt= 6 is selected, f400=3 to 5 do not work.
