E6581697
I-2
9
Table 1 EMC standards
Category Subcategory
Product
standards
Test standard
Radiation noise CISPR11(EN55011)
Emission
Conductive noise CISPR11(EN55011)
Static discharge IEC61000-4-2
Radioactive radio-frequency
magnetic contactor field
IEC61000-4-3
First transient burst IEC61000-4-4
Surge IEC61000-4-5
Radio-frequency
induction/transmission interference
IEC61000-4-6
Immunity
Voltage dip/Interruption of power
IEC 61800-3
IEC61000-4-11
9.1.2 Measures to satisfy the EMC directive
This subsection explains what measures must be taken to satisfy the EMC directive.
(1) This inverter is equipped with an EMC filter.
Table 2 Combinations of inverter and EMC filter
Single-phase 240 V class
Combination of inverter and filter
Inverter type
Conductive noise
IEC61800-3,
category C2
(PWM carrier
frequency of 4kHz
and motor wiring
length of 10m or less)
Conductive noise
IEC61800-3,
category C2
(PWM carrier
frequency of 12kHz
and motor wiring
length of 5m or less)
VFMB1S-2002PL
VFMB1S-2004PL
VFMB1S-2007PL
VFMB1S-2015PL
VFMB1S-2022PL
Built-in filter Built-in filter
