E6581697
K-30
11
 Communication option parameters
Title Function Reference
, 
Communication option common parameters 6.33.5

ProfiBus DP option parameters

DeviceNet option parameters
, 
EtherCAT option parameters

EtherNet common parameters

EtherNet/IP option parameters

Modbus TCP option parameters
, 
CANopen communication parameters 6.33.4
Note) Refer to each Instruction Manual for option about detailed specifications.
11.4 Default settings by inverter rating
Torque
boost value
Dynamic
braking
resistance
Dynamic
braking
resistor
capacity
Automatic
torque
boost value
Motor rated
capacity
Motor rated
current
Motor
no-load
current
Over-
voltage stall
protection
level
Integrating
wattmeter
display unit
selection
Inverter type
／

(%)

(Ω)

(kW)

(%)

(kW)

(A)

(%)

(%)

VFMB1S-2002PL 6.0 200.0 0.12 8.3 0.20 1.2 70 136 0
VFMB1S-2004PL 6.0 200.0 0.12 6.2 0.40 2.0 65 136 0
VFMB1S-2007PL 6.0 200.0 0.12 5.8 0.75 3.4 60 136 0
VFMB1S-2015PL 6.0 75.0 0.12 4.3 1.50 6.2 55 136 0
VFMB1S-2022PL 5.0 75.0 0.12 4.1 2.20 8.9 52 136 0
VFMB1-4004PL 6.0 200.0 0.12 6.2 0.40 1.0 65 141 0
VFMB1-4007PL 6.0 200.0 0.12 5.8 0.75 1.7 60 141 0
VFMB1-4015PL 6.0 200.0 0.12 4.3 1.50 2.4 55 141 0
VFMB1-4022PL 5.0 200.0 0.12 4.1 2.20 4.5 52 141 0
VFMB1-4037PL 5.0 160.0 0.12 3.4 4.00 *1 7.4 48 141 1
VFMB1-4055PL 4.0 80.0 0.24 2.6 5.50 10.5 46 141 1
VFMB1-4075PL 3.0 60.0 0.44 2.3 7.50 14.1 43 141 1
VFMB1-4110PL 2.0 40.0 0.66 2.2 11.00 20.3 41 141 1
VFMB1-4150PL 2.0 30.0 0.88 1.9 15.00 27.3 38 141 1
*1: When region setting is JP,  is set to 3.7(kW).
11.5 Default settings by setup menu
Frequency Base frequency voltage 1 & 2
V/F control mode
selection
Supply voltage
correction
(output voltage
limitation)
Motor rated
speed
,  (V)
Setting Main regions
, , ,
, ,
, ,
, 
(Hz)
240V class 500V class
 

(min
-1
)

Europe 50.0 230 400 0 2 1410
 Asia 50.0 230 400 0 2 1410
 North America 60.0 230 460 0 2 1710
 Japan 60.0 200 400 2 3 1710
Note) Refer to section 3.1 about setup menu.
