Page #128 background image
E6581697
F-8
6
6.3.2 Modifying input terminal functions
f111
: Input terminal selection 1A (F)
f112
: Input terminal selection 2A (R)
f113
: Input terminal selection 3A (RES)
f114
: Input terminal selection 4A (S1)
f115
: Input terminal selection 5 (S2)
f116
: Input terminal selection 6 (S3)
f151
: Input terminal selection 1B (F)
f152
: Input terminal selection 2B (R)
f153
: Input terminal selection 3B (RES)
f154
: Input terminal selection 4B (S1)
f155
: Input terminal selection 1C (F)
f156
: Input terminal selection 2C (R)
f109
: Analog/logic input selection (VIA/VIB)
f117
: Input terminal selection 7 (VIB)
f118
: Input terminal selection 8 (VIA)
Refer to section 7.2.1 for details about input terminal functions.
6.3.3 Modifying output terminal functions
f130
: Output terminal selection 1A (RY-RC)
f131
: Output terminal selection 2A (OUT)
f132
: Output terminal selection 3 (FL)
f137
: Output terminal selection 1B (RY-RC)
f138
: Output terminal selection 2B (OUT)
f139
: Output terminal logic selection (RY-RC, OUT)
Refer to section 7.2.2 for details about output terminal functions.
