E6581697
G-13
7
7.3 Speed instruction (analog signal) settings from
external devices
Function of analog input terminals can be
selected from four functions (external
potentiometer, 0 to 10Vdc, 4 (0) to 20mAdc,
-10 to +10Vdc).
The selective function of analog input
terminals gives system design flexibility.
The maximum resolution is 1/1000.
 Analog input terminal function settings
Terminal
symbol
Title Function Adjustment range Default setting
-
 Frequency priority selection 0, 1
0
 VIA input point 1 setting 0 - 100% 0
 VIA input point 1 frequency 0.0 - 500.0Hz 0.0
 VIA input point 2 setting 0 - 100% 100
VIA
 VIA input point 2 frequency 0.0 - 500.0Hz *1
-
 Frequency setting mode selection 2 0-11
1
VIA to VIC
 Analog input filter 4 - 1000 ms Note 1) 64

VIB input point 1 setting 0 - 100% 0

VIB input point 1 frequency 0.0 - 500.0Hz 0.0

VIB input point 2 setting 0 - 100% 100
VIB

VIB input point 2 frequency 0.0 - 500.0Hz
*1

VIC input point 1 setting 0 - 100% 0

VIC input point 1 frequency 0.0 - 500.0Hz 0.0

VIC input point 2 setting 0 - 100% 100
VIC

VIC input point 2 frequency 0.0 - 500.0Hz
*1
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
Note1) When stable operation cannot be attained because of frequency setting circuit noise, increase .
[Control terminal block]
FLA
FLC
FLB
CC
FM
CC
P24
CC
PP
VIB
VIC
VIA
RY
RC
OUT
NO
F
R
S1
S2
S3
RES
STO
+SU
SW2(S3)
LOGIC
PTC
SW1
SOURCE
PLC
SINK
