E6581697
F-111
6
6.29.6 Changing display of the status monitor
f711 to f718 : Status monitor 1 to 8
Change monitor display items in the status monitor mode.
Refer to chapter 8 for details.
6.29.7 Changing the status monitor condition
f709 : Standard monitor hold function
f746 : Status monitor filter
Function
The standard monitor display can be hold.
And a part of status monitors can be filtered to display.
, If is set to , the monitored values selected with (standard monitor display selection
parameter) are displayed. For peak hold values and minimum hold values, the minimum values in each
operation cycle are displayed. When the motor is at a standstill, the values monitored last are held as they
were until the motor is started the next time.
The maximum and minimum values monitored after power is turned on or after the reset with the EASY key
are always displayed no matter whether the motor is in operation or at a standstill.
, “Output current”, “Input voltage”, “Output voltage” and “Torque” can be filtered by f746.
Refer to chapter 8 about status monitor.
[Parameter setting]
Title Function Adjustment range Default setting
Standard monitor hold function
0: Real time
1: Peak hold
2: Minimum hold
0
f746 Status monitor filter 8-1000 (ms) 200
