Toshiba TOSVERT VF-MB1 User Manual

E6581697
F-122
6
Title Function Adjustment range Default setting
f856
Number of motor poles for
communication
1: 2 poles
2: 4 poles
3: 6 poles
4: 8 poles
5: 10 poles
6: 12 poles
7: 14 poles
8: 16 poles
2
f870 Block write data 1 0
f871 Block write data 2
0: No selection
1: Command information 1
2: Command information 2
3: Frequency command value
4: Output data on the terminal
board
5: Analog output for communication
6: Speed command value
0
f875 Block read data 1 0
f876 Block read data 2 0
f877 Block read data 3 0
f878 Block read data 4 0
f879 Block read data 5
0: No selection
1: Status information
2: Output frequency
3: Output current
4: Output voltage
5: Alarm information
6: PID feedback value
7: Input terminal board monitor
8: Output terminal board monitor
9: VIA terminal board monitor
10: VIB terminal board monitor
11: VIC terminal board monitor
12: Input voltage (DC detection)
13: Motor speed
14: Torque
0
f899 Communication function reset
0: -
1: Reset (after execution: 0)
0
*1: Disabled............ Indicates that the inverter will not be tripped even if a communication error occurs.
Trip................... The inverter trips when a communication time-over occurs.
In this case a trip information
err5 flashes on and off on the operation panel.
Alarm ............... When a communication time-over occurs, an alarm can be output from the output terminal.
Output terminal function: 78 (RS485 communication error) or 79 (RS485 communication
error reverse)
*2:Default setting values vary depending on the setup menu setting. Refer to section 11.5.
Note2) Changes to the parameters
f800, f801 and f806 do not take effect until the power is turned
off and then on again.
