E6581697
K-3
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0009 Acceleration time
1
s 0.1/0.1 0.0-3600 (360.0) *8 10.0 5.4
0010 Deceleration time
1
s 0.1/0.1 0.0-3600 (360.0) *8 10.0
0011 Maximum
frequency
Hz 0.1/0.01 30.0-500.0 80.0 5.9
0012 Upper limit
frequency
Hz 0.1/0.01 0.5- *1 5.10
0013 Lower limit
frequency
Hz 0.1/0.01 0.0- 0.0
0014 Base frequency 1 Hz 0.1/0.01 20.0-500.0 *1 5.11
0409 Base frequency
voltage 1
V 1/0.1 50-330 (240V class)
50-660 (500V class)
*1 5.11
6.15.6
0015 V/F control mode
selection
- - 0: V/F constant
1: Variable torque
2: Automatic torque boost control
3: Vector control
4: Energy-saving
5: Dynamic energy-saving
(For fan and pump)
6: PM motor control
7: V/F 5-point setting
8: -
*1 5.12
0016 Torque boost
value 1
% 0.1/0.1 0.0-30.0 *2 5.13
0600 Motor electronic-
thermal protection
level 1
%
(A)
1/1 10-100 100 3.5
5.14
6.24.1
Sett ing Overload protection OL stall
0 valid invalid
1 valid valid
2 invalid invalid
3
Standard
motor
invalid valid
4 valid invalid
5 valid valid
6 invalid invalid
0017 Electronic-thermal
protection
characteristic
selection
- -
7
VF motor
invalid valid
0 3.5
5.14
0018 Preset-speed
frequency 1
Hz 0.1/0.01 - 0.0
0019 Preset-speed
frequency 2
Hz 0.1/0.01 - 0.0
0020 Preset-speed
frequency 3
Hz 0.1/0.01 - 0.0
0021 Preset-speed
frequency 4
Hz 0.1/0.01 - 0.0
0022 Preset-speed
frequency 5
Hz 0.1/0.01 - 0.0
0023 Preset-speed
frequency 6
Hz 0.1/0.01 - 0.0
0024 Preset-speed
frequency 7
Hz 0.1/0.01 - 0.0
3.6
5.15
0025 Process input
value of PID
control
Hz 0.1/0.01
f368 -
0.0 5.16
6.20
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
*2: Default setting values vary depending on the capacity. Refer to section 11.4.
*8: These parameters can be changed to 0.01s unit by setting f519=1.
To Next Page
