E6581697
K-11
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0: Carrier frequency without reduction
1: Carrier frequency with automatic
reduction
2: Carrier frequency without reduction
(Support for 500V models)
0316 Carrier frequency
control mode
selection
- -
3: Carrier frequency with automatic
reduction
(Support for 500V models)
1 6.14
0317 Synchronized
deceleration time
(time elapsed
between start of
deceleration to
stop)
s 0.1/0.01 0.0-3600 (360.0) 2.0 6.15.2
0318 Synchronized
acceleration time
(time elapsed
between start of
acceleration to
achievement of
specified speed)
s 0.1/0.01 0.0-3600 (360.0) 2.0
0319 Regenerative
over-excitation
upper limit
% 1/1 100-160 120 6.15.5
0320 Droop gain % 0.1/0.1 0.0-100.0 0.0 6.16
0323 Droop insensitive
torque band
% 1/1 0-100 10
0324 Droop output filter - 0.1/0.1 0.1-200.0 100.0
0328 Light-load high-
speed operation
selection
- - 0:Disabled
1:High-speed operation speed set
automatically (Power running at F
command: Increase)
2:High-speed operation speed set
automatically (Power running at R
command: Increase)
3:High-speed operation speed set
with f330 (Power running at F
command: Increase)
4:High-speed operation speed set
with f330 (Power running at R
command: Increase)
0 6.17
0329 Light-load high-
speed learning
function
- - 0:No learning
1:Forward run learning
2:Reverse run learning
0
0330 Automatic light-
load high-speed
operation
frequency
Hz 0.1/0.01 30.0-ul *1
0331 Light-load high-
speed operation
switching lower
limit frequency
Hz 0.1/0.01 5.0-ul 40.0
0332 Light-load high-
speed operation
load waiting time
s 0.1/0.1 0.0-10.0 0.5
0333 Light-load high-
speed operation
load detection
time
s 0.1/0.1 0.0-10.0 1.0
*1: Default setting values vary depending on the setup menu setting. Refer to section 11.5.
