E6581697
K-19
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0678 Pulse train output
filter
ms 1/1 2-1000 64
6.28.1
0679 Pulse train input
filter
ms 1/1 2-1000 2
6.6.5
0681 Analog output
signal selection
- - 0: Meter option (0 to 1 mA)
1: Current (0 to 20 mA) output
2: Voltage (0 to 10 V) output
0
3.4
6.28.2
0684 Analog output
filter
ms 1/1 2-1000 2
0691 Inclination
characteristic of
analog output
- - 0: Negative inclination (downward
slope)
1: Positive inclination (upward slope)
1
0692 Analog output bias % 0.1/0.1 -1.0－+100.0 0.0
0693 Factory specific
coefficient 6B
- - - - * 3
*3: Factory specific coefficient parameters are manufacturer setting parameters. Do not change the value of these parameters.
Operation panel parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0700
Parameter
protection
selection
- - 0: Permitted
1: Writing prohibited (Panel and
extension panel)
2: Writing prohibited (1 + RS485
communication)
3: Reading prohibited (Panel and
extension panel)
4: Reading prohibited (3 + RS485
communication)
0 6.29.1
0701
Current/voltage
unit selection
- - 0: %
1: A (ampere)/V (volt)
0 6.29.2
0702
Frequency free
unit display
magnification
Times 0.01/0.01 0.00: Disabled (display of frequency)
0.01-200.0
0.00 6.29.3
0703
Frequency free
unit coverage
selection
- 1/1 0: All frequencies display
1: PID frequencies display
0
0705
Inclination
characteristic of
free unit display
- 1/1 0: Negative inclination (downward
slope)
1: Positive inclination (upward slope)
1
0706
Free unit display
bias
Hz 0.1/0.01 0.00- 0.00
0707
Free step 1
(1-step rotation of
setting dial)
Hz 0.01/0.01 0.00: Automatic
0.01-
0.00 6.29.4
0708
Free step 2 (panel
display)
- - 0: Automatic
1-255
0
0709
Standard monitor
hold function
- - 0: Real time
1: Peak hold
2: Minimum hold
0 6.29.7
