E6581697
K-21
11
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
0711
Status monitor 1 - - 2 6.29.6
8.2.1
8.3.2
0712
Status monitor 2 - - 1
0713
Status monitor 3 - - 3
0714
Status monitor 4 - - 4
0715
Status monitor 5 - - 5
0716
Status monitor 6 - - 6
0717
Status monitor 7 - - 27
0718
Status monitor 8 - -
0: Output frequency (Hz/free unit)
1: Output current (%/A)
2: Frequency command value
(Hz/free unit)
3: Input voltage (DC detection) (%/V)
4:
Output voltage (command value) (%/V)
5: Input power (kW)
6: Output power (kW)
7: Torque (%)
8: -
9: Motor cumulative load factor
10: Inverter cumulative load factor
11: PBR (Braking resistor) cumulative
load factor
12: Stator frequency (Hz/free unit)
13: VIA input value (%)
14: VIB input value (%)
15 to 19: -
20: VIC input value (%)
21: Pulse train input value (kpps)
22: -
23: PID feedback value (Hz/free unit)
24: Integral input power (kWh)
25: Integral output power (kWh)
26: Motor load factor (%)
27: Inverter load factor (%)
28: Inverter rated current (A)
29: FM output value (%)
30: Pulse train output value (kpps)
31: Cumulative power on time (100
hours)
32: Cumulative fan operation time
(100 hours)
33: Cumulative operation time (100
hours)
34: Number of starting (10000 times)
35: Forward number of starting
(10000 times)
36: Reverse number of starting
(10000 times)
37 to 39: -
40: Inverter rated current (Carrier
frequency corrected)
41 to 51: -
52: Frequency command value /
output frequency (Hz/free unit)
0
0719
Canceling of
operation
command
- - 0: Panel operation command
canceled (cleared)
1: Operation command retained
2: Panel/Communication operation
command canceled (cleared)
1 6.29.8
0720
Initial extension
panel display
selection
- - 0-52 (Same as f710) 0 6.29.5
8.3.2
0721
Panel stop pattern - - 0: Deceleration stop
1: Coast stop
0 6.29.9
0729
Operation panel
override
multiplication gain
% 1/1 -100-+100 0 6.26
