Toshiba TOSVERT VF-MB1 User Manual

E6581697
K-27
11
 Logic sequence parameters
Title
Communication
No.
Function Unit
Minimum
setting unit
Panel/Commun
ication
Adjustment range
Default
setting
User
setting
Reference
 A900
Input function
target 11
- - Input terminal function number
0: No function
1: Terminal F
2: Terminal R
3: Terminal RES
4: Terminal S1
5: Terminal S2
6: Terminal S3
7: Terminal VIB
8: Terminal VIA
9 to 20: -
21 to 24: Virtual input terminal 1 to 4
25 to 32: Internal terminal 1 to 8
918 to 934: Logic sequence function
number
1000 to 1255: Output selection number
2000 to 2099: FD00 to FD99
3000 to 3099: FE00 to FE99
0 6.36
 A901
Input function
command 12
- -
0:NOP (not operation)
1:ST (move)
2:STN
3:AND (logical product)
4:ANDN
5:OR (logical sum)
6:ORN
7:EQ (equal)
8:NE (not equal)
9:GT (greater than)
10:GE (greater or equal)
11:LT (less than)
12:LE (less or equal)
13:ASUB (absolute)
14:ON (on delay timer)
15:OFF (off delay timer)
16:COUNT 1 (counter 1)
17:COUNTR 2 (counter 2)
18:HOLD (hold)
19:SET (set)
20:RESET (reset)
21:CLR
22:CLRN
0
 A902
Input function
target 12
- -
0-3099 (Same as a900) 0
 A903
Input function
command 13
- -
0-22 (Same as a901) 0
 A904
Input function
target 13
- -
0-3099 (Same as a900) 0
 A905
Output function
assigned object 1
- -
0-3099 (Same as a900) 0
 A906
Input function
target 21
- -
0-3099 (Same as a900) 0
 A907
Input function
command 22
- -
0-22 (Same as a901) 0
 A908
Input function
target 22
- -
0-3099 (Same as a900) 0
 A909
Input function
command 23
- -
0-22 (Same as a901) 0
 A910
Input function
target 23
- -
0-3099 (Same as a900) 0
 A911
Output function
assigned object 2
- -
0-3099 (Same as a900) 0
