E6581697
K-39
11
Table of output terminal functions 5
Function
No.
Code Function Action Reference
222 LSFO1 Logic sequence function output 1 ON: Logic sequence function output 1 is ON
OFF: Logic sequence function output 1 is OFF
6.36
223 LSFO1N Inversion of logic sequence function output 1 Inversion of LSFO1
224 LSFO2 Logic sequence function output 2 ON: Logic sequence function output 2 is ON
OFF: Logic sequence function output 2 is OFF
225 LSFO2N Inversion of logic sequence function output 2 Inversion of LSFO2
226 LSFO3 Logic sequence function output 3 ON: Logic sequence function output 3 is ON
OFF: Logic sequence function output 3 is OFF
227 LSFO3N Inversion of logic sequence function output 3 Inversion of LSFO3
228 LSFO4 Logic sequence function output 4 ON: Logic sequence function output 4 is ON
OFF: Logic sequence function output 4 is OFF
229 LSFO4N Inversion of logic sequence function output 4 Inversion of LSFO4
230 LSFO5 Logic sequence function output 5 ON: Logic sequence function output 5 is ON
OFF: Logic sequence function output 5 is OFF
231 LSFO5N Inversion of logic sequence function output 5 Inversion of LSFO5
232 LSFO6 Logic sequence function output 6 ON: Logic sequence function output 6 is ON
OFF: Logic sequence function output 6 is OFF
233 LSFO6N Inversion of logic sequence function output 6 Inversion of LSFO6
234 LSFO7 Logic sequence function output 7 ON: Logic sequence function output 7 is ON
OFF: Logic sequence function output 7 is OFF
235 LSFO7N Inversion of logic sequence function output 7 Inversion of LSFO7
236 LSFO8 Logic sequence function output 8 ON: Logic sequence function output 8 is ON
OFF: Logic sequence function output 8 is OFF
237 LSFO8N Inversion of logic sequence function output 8 Inversion of LSFO8
238 LSFO9 Logic sequence function output 9 ON: Logic sequence function output 9 is ON
OFF: Logic sequence function output 9 is OFF
239 LSFO9N Inversion of logic sequence function output 9 Inversion of LSFO9
240 LSFO10 Logic sequence function output 10 ON: Logic sequence function output 10 is ON
OFF: Logic sequence function output 10 is OFF
241 LSFO10N Inversion of logic sequence function output 10 Inversion of LSFO10
242 LSFO11 Logic sequence function output 11 ON: Logic sequence function output 11 is ON
OFF: Logic sequence function output 11 is OFF
243 LSFO11N Inversion of logic sequence function output 11 Inversion of LSFO11
244 LSFO12 Logic sequence function output 12 ON: Logic sequence function output 12 is ON
OFF: Logic sequence function output 12 is OFF
245 LSFO12N Inversion of logic sequence function output 12 Inversion of LSFO12
246 LSFO13 Logic sequence function output 13 ON: Logic sequence function output 13 is ON
OFF: Logic sequence function output 13 is OFF
247 LSFO13N Inversion of logic sequence function output 13 Inversion of LSFO13
248 LSFO14 Logic sequence function output 14 ON: Logic sequence function output 14 is ON
OFF: Logic sequence function output 14 is OFF
249 LSFO14N Inversion of logic sequence function output 14 Inversion of LSFO14
250 LSFO15 Logic sequence function output 15 ON: Logic sequence function output 15 is ON
OFF: Logic sequence function output 15 is OFF
251 LSFO15N Inversion of logic sequence function output 15 Inversion of LSFO15
252 LSFO16 Logic sequence function output 16 ON: Logic sequence function output 16 is ON
OFF: Logic sequence function output 16 is OFF
253 LSFO16N Inversion of logic sequence function output 16 Inversion of LSFO16
254 AOFF Always OFF Always OFF 7.2.2
255 AON Always ON Always ON
Note 1: As function No. that are not described in the table above are assigned "No function", output signal is always “OFF”
at even number, output signal is always “ON” at odd number.
