E6581697
C-3
3
Values set by each setup parameter
Title Function
(Mainly in
Europe)
(Mainly in
North America)
(Mainly in Asia,
Oceania)
Note 1)
(Mainly in
Japan)
/
/
Frequency settings
50.0(Hz) 60.0(Hz) 50.0(Hz)
60.0(Hz)
/
/
/
/
/
Input point 2 frequency
50.0(Hz) 60.0(Hz) 50.0(Hz)
60.0(Hz)
240V class
230(V) 230(V) 230(V) 200(V)
/
Base
frequency
voltage 1, 2
500V class
400(V) 460(V) 400(V)
400(V)
V/F control mode selection
0 0 0
2
Supply voltage correction
(output voltage limitation)
2 2 2 3
Motor rated speed
1410(min
-1
) 1710(min
-1
) 1410(min
-1
) 1710(min
-1
)
Note 1) Excludes Japan.
Note 2) Slide switch SW1 is set to PLC side at default setting. Set it appropriately according to the logic used.
Refer to page B-11 and 12 for details.
To Next Page
