TRANSPORTATION AND INSTALLATION MANUAL
12
Equipment Configuration Drawing (For the TSL3100E)
1.1.2.
Fig. 1.2 Equipment Configuration (TSL3100E)
As for the connection method of power supply 200V, see "8.1.2 Connecting the Power
Cable "ACIN"". Again, for the connection method of power supply 24V, see "8.1.5
Connecting Power Supply Cable for External Input/Output".
TP cable
TVL500
Cable between the robot and the
controller
For TSPC6ax
communication
cable (provided
by the customer)
PC (provided by the
customer)
Program support software
TSPC6ax (option)
TCPRGOS (option)
200V power
supply
24V power
supply
RS-232C (cross cable )
or
LAN cable (cross cable)
Teaching pendant (option)
Robot controller
TSL3100E
