TRANSPORTATION AND INSTALLATION MANUAL
14
1.2. Name of Each Part
Fig. 1.4 shows the name of each part of the robot of the TVL series.
Fig. 1.4 Name of each part (TVL500)
Base swivel
Arm 1
Axis 1
(rotation)
Axis 3
(rotation)
Axis 2
(rotation)
Base
Arm 2 (1)
Axis 6
(rotation)
Axis 5
(rotation)
Axis 4
(rotation)
Arm 2 (2)
Arm 3
Cable duct
HAND I/O connector
Tool tube joint (4 mm diameter):
4 locations
Tool tube joint
(4 mm diameter):
4 locations
HAND signal/brake
cable connector
Motor power/encoder
cable connector
Grommet for wiring hole
