Toyota 8FGCU25 Repair Manual

3-173 MATERIAL HANDLING SYSTEM
3 MATERIAL HANDLING SYSTEM
3.1 HYDRAULIC CIRCUIT DIAGRAM........................................................... 17
3.2 COMPONENTS ....................................................................................... 21
3.1 HYDRAULIC CIRCUIT DIAGRAM
4YE and 1ZS engine
Without oil cooler
(3)
(7)
(1)
(8)
(2)
(4)
(5)
(6)
(1) Oil pump
(2) Priority valve
(3) Oil control valve
(4) Steering valve
(5) Solenoid valve (OPT)
(6) Power steering cylinder
(7) Lift, tilt and ATT cylinder
(8) Oil tank
3

Toyota 8FGCU25 Specifications

General

Load Capacity	5000 lbs
Lift Height	189 inches
Power Source	Internal Combustion
Fuel Type	Gasoline/LPG
Operator Type	Seated
Lift Speed (loaded/unloaded)	122 fpm
Lowering Speed (loaded/unloaded)	98 fpm / 98 fpm
Mast Height (lowered/raised)	83 inches
Weight	3, 500 kg
