7-577 DISPLAY
7.1.3 SCREEN
7.1.3.1 Initial screen after Key-On
The initial screen is displayed for about 1 second after the key switch is turned ON.
7.1.3.2 Status screen
The status screen is displayed after the initial screen.
Function activation indicator
Speedometer
Function activation indicator
Low speed setting indicator
Eco-mode indicator
Menu lock indicator
Torque converter oil temperature indicator
7
