Chapter 1
1. 1. Product Overview
TP-Link’s modem router is a combined wired/wireless network connection device with
wireless router and DSL modem capabilities.
With DSL and LAN/WAN ports, the modem router is compatible with DSL connections
and fiber/cable access.
Ethernet ports and adjustable antennas enable the modem router to provide wired and
wireless access for multiple computers and mobile devices.
With an array of additional features, the modem router is the perfect hub for your home
or business network.
1. 2. Physical Appearance
1. 2. 1. Top Panel
The modem router’s LEDs are located on the top panel. You can check the modem
router’s working status by following the LED Explanation table.
It also provides the LED On/Off button. You can press the button to turn on/off the LEDs
without affecting the modem router’s function.
LED On/Off Button
