94
Chapter 15
Specify Your Network Settings
shown in the following figure so that the physical connection between my PC and my
company’s server is achieved. To surf the internet and visit my company’s network at
the same time, I need to configure the static routing.
Company’s server
My PC
Router 2
Modem router
Switch
LAN: 192.168.1.1
192.168.1.100
LAN: 192.168.1.2
WAN: 172.30.30.100
172.30.30.1
How can I do that?
1. Make sure the routers use different LAN IP addresses on the same subnet. Disable
Router 2’s DHCP function.
2. Visit http://tplinkmodem.net, and log in with your TP-Link ID or the password you
set for the router.
3. Go to Advanced > Network > Static Routing. Select your current WAN Interface and
click Save.
4. Click Add to add a new static routing entry. Finish the settings according to the
following explanations:
