HARDWARE FEATURES
Frequency Plan DOCSIS Annex B
Symbol Rate DOCSIS 64 QAM 5.057 Msym/s; 256 QAM 5.361 Msym/s
Operating Level Range
–15 to 15 dBmV (DOCSIS)
Security DOCSIS 3.0 Security (BPI+, EAE, SSD)
DOCSIS UPSTREAM
Channel Binding Up to 4
Modulation QPSK and 8, 16, 32, 64, 128, 256 QAM
Maximum PHY Rate
Up to 30Mbps for Single Channel and 4p to 120 Mbps for 4 channel
bonding both for DOCSIS
Channel Bandwidth 200 kHz, 400 kHz, 800 kHz, 1.6 MHz,3.2 MHz, 6.4 MHz
Frequency Range DOCSIS 5-42 MHz (edge to edge),
Symbol Rate 160, 320, 640, 1280, 2560, 5120 ksym/s
Level range
TD MA
Pmin to +57 dBmV (32 QAM, 64 QAM)
Pmin to +58 dBmV (8 QAM, 16 QAM)
Pmin to +61 dBmV (QPSK)
Note: TDMA max output power reduced 3dB when transmitting two
channels and 6dB when transmitting 3 or 4 channels
S-CDMA
Pmin to +56 dBmV (all modulations)
Pmin = +20 dBmV, 2560 kHz modulation rate
Pmin = +23 dBmV, 5120 kHz modulation rate
Note: S-
