Appendix A: Specifications
HARDWARE FEATURES
Interface
1 F-Connector, female 75 Ω
4 10/100/1000Mbps RJ45 LAN Ports
2 USB 2.0 Ports
Button
1 Power On/Off Button
1 Wi-Fi On/Off Button
1 WPS Button
1 Reset Button
External Power Supply 12VDC/3.5A
IEEE Sta nda r ds IEEE 802.3, 802.3u
DOCSIS Standards
DOCSIS 3.0
DOCSIS 2.0
DOCSIS 1.1
DOCSIS 1.0
Dimensions ( W x D x H ) 2.5× 7.7× 9.7 in. (62.5× 195× 246 mm)
Antenna Type Omni directional, Internal
Antenna Gain 3×5 dBi for 2.4GHz and 5GHz
DOCSIS Dow nstream
Channel Binding Up to 16
Modulation 64 /256 / 1024 QAM
Maximum PHY Rate DOCSIS Up to 680 Mbps
Bandwidth DOCSIS 96 MHz(16 channels) / 6MHz (single channel)
Frequency Range 108 to 1002 MHz (edge to edge)
91
