Note:
To access the router, you should type your router's WAN IP address into your browser's
address (in IE) or Location (in Navigator) box, followed by a colon and the custom port
number. For example, if your router's WAN address is 202.96.12.8, and the port number used
is 8080, please enter http://202.96.12.8:8080 in your browser. Later, you may be asked for
the router's password. After successfully entering the username and password, you will be
able to access the router's web-based utility.
WAN Blocking:
WAN Blocking – Check the Enable to block anonymous Internet requests.
Click the Sav e button save the settings.
5.10.8 Event Log
Choose menu “Adv ance d
Event Log”, and then you can view and clear the
logs of the modem router.
Figure 5-67
Clear Log – Click to delete all the logs.
90
