Chapter 3. Configure the Modem Router
With a Web-based management page, it is easy to configure and manage the Archer CR700
AC1750 Wireless Dual Band DOCSIS 3.0 Cable Modem Router. The Web-based management
page can be used on any Windows, Macintosh or UNIX OS with a Web browser, such as Microsoft
Internet Explorer, Mozilla Firefox or Apple Safari.
Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC. If you
need instructions as to how to do this, please refer to Appendix B: Trouble shooting
.
To access the configuration utility, open a web-browser and type the default address
http://tplinkmodem.net/ or 192.168.1.1
in the address field of the browser.
Figure 3-1
After a moment, a login window will appear. Enter admin for the Username and Password, both in
lower case letters. Then click the Login button or press the Enter key.
Figure 3-2
After your successful login, you will see the screen as shown below.
Figure 3-3
10
