1.3.2 The Back Panel
Figure 1-2
RESET: There are two ways to reset the modem router's factory defaults.
Method one: With the modem router powered on, use a pin to press and hold the Reset
button for at least 8-10 seconds. And the modem router will reboot to its factory default
settings.
Method two: Restore the default setting from “5.10.6 Backup & Restore
” of the modem
router's Web-based Management.
WPS: The switch for the WPS function.
WiFi ON/OFF: The switch for the WiFi function. Press it to enable/disable the WiFi function.
USB2, USB1: The USB port connects to a USB storage device or a USB printer.
LAN4, L AN3, LAN2, L AN1 : Through these ports, you can connect the modem router to your
PC or the other Ethernet network devices.
Cable : Through this port, you can connect the modem router to coaxial cable.
DC: The power plug where you will connect the power adapter.
Powe r ON/OFF: The switch for the power.
6
