Figure 5-37
IP Filtering:
Start/End IP Address –Display the start IP Address/end IP Address of the client that cannot
access this router.
Enable - Click the icon to enable the function. If this function has taken effect, the icon
will become .
Modify - Click the icon to edit the corresponding entry. If you want to delete this entry,
you can click the
icon.
To add a IP Address Filtering entry:
1. Click
button, then you will see a setting page.
2. Enter the Start IP Address and the End IP Address.
3. Check Enable this Entry for this entry, as shown in the following figure.
Figure 5-38
4. Click the OK button to save this entry. If you do not want to save this entry, click the Cancel
button.
61
