6
Chapter 1
Get to Know About Your Modem Router
1. 3. 2. The Back Panel
The extender’s back panel shows the connection ports, buttons and antennas. Refer to
the following for detailed instructions.
Item
Description
Power For connecting the extender to power socket via the provided power adapter.
Power On/Off The switch for the power. Press it to power on or off your extender.
Ethernet (1, 2, 3, 4)
Used for connecting to Ethernet-enabled device, such as smart TV, game
console, desktop, DVR, etc.
Reset
With the extender powered on, use a pin to press and hold the Reset button
until the RE590T logo displays.
Antennas
Used for wireless operation and data transmit. Upright them for the best Wi-Fi
performance.
