The lock attribute can be set in the measuring system only after the user has verified
the correct function of the measuring system by a test run in safe mode.
To meet this requirement, the user must integrate the measuring system in this phase into the
intended application and verify the correct function through a test run in safe mode.
If readjustments are necessary, perform the steps of
- setting parameters
- calculating (SCTS, SCCRC)
- downloading the configuration
- Function test
repeatedly as described above.
It is recommended to save the configuration of a successful test for further configuration transfers or
later verifications via the menu item File ->Save.
Now upload the configuration from the measuring system to the SNCT tool and
compare it as the measuring system has received the configuration from the TR
SCNT tool. The configuration can be locked only if the data match.
To meet this requirement, the measuring system must be reconnected to the TR SNCT tool. Ensure
that no controller is connected to the measuring system. that there is no EtherNet/IP™
communication, and that the correct configuration has been selected for the verification. Activate the
SNCT function SNCT Download -> Upload for the upload.
The Upload button transfers the SCCRC and SCTS determined or saved by the measuring system and
writes them into the appropriate fields in the Configuration Verification section.
The fields SCCRC and SCTS are highlighted in yellow if the values differ from the configuration
download data.
The transmitted SCID and configuration data must be compared with the SCID and
configuration data originally displayed on the PC.
Visually verify that all configuration data have been correctly downloaded to the
measuring system.
Use the Show button to read in and display the data automatically saved on the hard drive after the
upload and meet this requirement. The divers display uses an independent and separate editor.
Compare the data displayed in the editor (Device SCID) with the configuration download data (Tool
SCID). These must be identical to meet the requirements of a Safety configuration. Close the editor
via the Shut down button.
